Question: The system is released from rest at = 0 when a constant couple moment M = 1 0 0 N * m is applied. (

The system is released from rest at =0 when a constant couple moment M=100N*m is applied. (Figure 1)
If the mass of the cable and links AB and BC can be neglected, and each pulley can be treated as a disk having a mass of 6 kg , determine the speed of the 16-kg block at the instant link AB has rotated =90. Note that point C moves along the vertical guide. Also, the cable does not slip on the pulleys.
Express your answer to three significant figures and include the appropriate units.
Request Answer
Provide Feedback
Figure
1 of 1
The system is released from rest at = 0 when a
