Part I 1) Research and create a schematic using Logic.ly as shown below. a. For each gate: NOT, AND, OR, NAND, NOR, XOR i. Use 2 inputs labeled A and B. One output for each gate. ii. Draw the equivalent of the gate using only NAND gates iii. Draw the equivalent of the gage using only NOR gates b. Create a screen-shot of each possible combination of the A and B inputs, showing the state of the output 'bulbs'. 2) In your report describe how the equivalency is accomplished, use Boolean equations. = NOT Examples of NOT using NAND and NOR, as well as AND below: (you do not have to copy the format exactly) NOT wsing NAND NOT using NOR ANDI NAND AND NOR Logic.Ly is an online browser based logic simulation tool. www.logic.ly Download Logicly 1.12.1 Use the Free Trial, Teach logic gates digital circuits effectively - with Logicly so that and browser addition Doga cecult quickly and the maste inte hangende egen, more Dale castelo debent the props you diep by - Det allero bo wiados for easiest access. Buy Logic Free Trial Part I 1) Research and create a schematic using Logic.ly as shown below. a. For each gate: NOT, AND, OR, NAND, NOR, XOR i. Use 2 inputs labeled A and B. One output for each gate. ii. Draw the equivalent of the gate using only NAND gates iii. Draw the equivalent of the gage using only NOR gates b. Create a screen-shot of each possible combination of the A and B inputs, showing the state of the output 'bulbs'. 2) In your report describe how the equivalency is accomplished, use Boolean equations. = NOT Examples of NOT using NAND and NOR, as well as AND below: (you do not have to copy the format exactly) NOT wsing NAND NOT using NOR ANDI NAND AND NOR Logic.Ly is an online browser based logic simulation tool. www.logic.ly Download Logicly 1.12.1 Use the Free Trial, Teach logic gates digital circuits effectively - with Logicly so that and browser addition Doga cecult quickly and the maste inte hangende egen, more Dale castelo debent the props you diep by - Det allero bo wiados for easiest access. Buy Logic Free Trial
