Question: Given the following information below a) Draw the Project Network. b) Compute the ES, EF, LS and LF. . Calculate Float Times for the project

Given the following information below a) Draw the Project Network. b)

Given the following information below a) Draw the Project Network. b) Compute the ES, EF, LS and LF. . Calculate Float Times for the project network. c) Which activities on the critical path have only the start or finish of the activity on the critical path? d) Draw the Gantt Chart of the project

Step by Step Solution

There are 3 Steps involved in it
